• It can measure up to 1000V AC/DC

• Equipped with audible and visible alarm, this series can provide warning expecially when measuring high voltage/current and temperature

• True RMS

• Data hold/backlight

• Max/Min/Relative mode

• USB communication

• Input protection

• Diode/continuity test

• NCV (audible/visual alarm)

• LPF ACV

• ACV+DCV

• Transistor hFE

• Peak Hold

Specifications:

• Safety ratings: CAT III 1000V/CAT IV 600V

• AC voltage: 1000V ±(0.8%＋10)

• DC voltage: 1000V ±(0.05%＋5)

• AC current: 20A ±(0.8%＋10)

• DC current: 20A ±(0.5%＋10)

• Resistance: 220MΩ ±(0.5%＋10)

• Capacitance: 220mF ±(3%＋5)

• Frequency: 220MHz ±(0.01%＋5)

• Duty cycle: 0.1%~99.9% ±(2%＋5)

• Display count: 22000

• Bandwidth: 40~10kHz

• LPF ACV: Support

• ACV+DCV: Support

• Transistor hFE: Support

• Peak Hold: Support

• Analog bar: 46

• Power: 1.5V battery (R03) x 4

• Product size: 190mm x 90mm x 50mm

• Product net weight: 350g
