• Automatically detect channel configuration at startup
• Support L1 sub-state deep power saving mode
• Support wakeup function in S3/S4
• The operating temperature range is 0~85 degrees Celsius
• Support hot swap, drive-free, plug and play
• Suitable system: Windows 7/8/8.1/10 (32 or 64 bit), for Linux Kernel 3.17 or later
• Built-in one available PCI Express x16 slot
• Compliant with PCI Express Specification Revision v3.0
• Backward compatible with PCIe 2.0 and PCIe 1.0
• Support for NVM Express (NVMe), M.2 Specification Revision 0.9
• Supports quad-port x4-lane M.2 Key M NVMe SSD devices
• Support M.2 SSD module size: 2230, 2242, 2260, 2280
• Supports M.2 "M" keys and "B+M" keys via PCIe protocol

Specification:

• Chipset: ASMedia/ASM2824
• Bus Type: PCIe 3.0 x16
• Media Interface: 4 x M.2 M KEY NVMe SSD
• Module size: M.2 Key M NVMe SSD devices supporting 2230, 2242, 2260, 2280
