Specifications:
Category | Type | Parameter |
system | operating system | linux |
Number of online users | 4 users watch online at the same time | |
APP | OKAM | |
collection | processor | T31 |
Memory | 8M | |
Image Sensor | GC2083, 1/3 CMOS (pixel optional, PCB compatible) | |
Minimum illumination | 0.3~0.5Lux (color mode), 0Lux (black and white mode) | |
lens | 4G lens, integrated IR CUT, standard lens diameter 10mm | |
Viewing angle | D135° diagonal | |
video | night vision | Black and white night vision, photosensitive automatic recognition of light switching, 8 940nm non-luminous patch infrared lights, illumination distance 3 to 5 meters |
Compression standard | H.264/MJPEF/JPEG | |
Multiple streams | Main stream: 1080P/15fps Sub-stream: 360P/15fps | |
Code rate | CBR/VBR two code rate control modes, and the output code rate range is 128~4096kbps | |
Image adjustment | Brightness, contrast, vertical, horizontal adjustable, OSD display | |
Audio | enter | Built-in-38dB microphone |
output | Built-in 8Ω 1W speaker | |
Sampling frequency/bit width | 8KHz/16bit | |
Compression standard/code rate | G711A | |
AI | Humanoid detection | Humanoid detection, filtering invalid event alarms |
Area detection | Customize the monitoring area to only monitor the areas that users care about | |
Smart notification sound | The push sounds from different devices are differentiated, and you can accurately know which device was triggered. | |
Smart alarm sound | Set different device alarm sounds according to different scenarios | |
More AI functions (under internal testing) | Pets, vehicles, packages, etc. | |
network | Wireless connections | Scan the device QR code to add/the device scans the APP QR code |
domestic | FDD:B1/B3/B5/B8 TDD:B34/B38/B39/B40/B41 | |
button | Toggle button 1 | Turn on and off |
Toggle button 2 | Mode switching (4G networking mode and DV local recording mode switching) | |
reset button | Long press to restore factory settings | |
storage | External TF card | Support T-Flash card (up to 256GB, not included) |
cloud storage | 3 days free cloud storage | |
alarm | Alarm detection | Support human motion detection, PIR infrared human detection |
Physical indicators | Charging voltage | DC5V±5% |
powered by | Comes with 3000mAh battery power supply | |
Power consumption | Sleep standby current 5mA, working: 400-600mA | |
working environment | Working temperature: -10~55℃, working humidity <90% | |
size | 52x37x40mm, length, width and height |
