• It detects the temperature

• You can set the start and stop the temperature

• Screen lock protection function

• Cycle timing, start and stop time, timer switch

• Widely used in intelligent control, such as carbon heating, aquaculture, greenhouse, home life, and other places

• Press the RESET to restore the screen for one second, and restore the factory settings

• Memory function after power off

Specification:

• Voltage: 110V~230V AC 50Hz/60Hz

• EU FR Plug: 16(2)A 230V-Max. 3680W.u

• UK Plug: 13(2)A 230V-Max. 2900W.u

• AU Plug: 10(2)A 240V-Max. 2400W.u

• US Plug: 15(2)A 120V-Max. 1800W.u

• Temperature range: -40~120°C

• Accuracy: +/- 1%

• Timing Accuracy: 10 minutes max

• Open circuit (or less than -40°C), the first row of the screen flashes display "E1", -40~-45°C, display -40°C.

• Short circuit( or more than 120°C ), the first row of the screen flashes display "E2", 121-129°C display 120°C

• Lower than -10°C, or higher than 100°C, it will not display value behind the decimal point

• Refrigeration mode, start temperature > Stop temperature

• Heating mode, start temperature < Stop temperature

Mode Button:

• Press MODE. LCD display: temperature control mode

• Timing mode F01-F04

• F01 Cycling timing mode, start time(ON)/stop time(OFF) cycling timing.

• F02 Count down ON mode, now Ti. s OFF, delayed(start time) ON

• F03 Count down OFF mode, now Ti. s ON, delayed(stop time) OFF, countdown completion, turn off the output and exit the run

• F04 Count down ON Count down OFF mode, now Ti. s OFF, delayed(start time) ON, After starting delayed ( Stop time )OFF, Stop the time to finish the countdown, close out the output and exit the operation

Temperature Correction Function:

• Long press mode button on electricity, real time temperature calibration after 2 seconds

• Real time temperature correction range: -9.9~9.9°C

• Long press the SET for 5 seconds to automatically exit, do not save modification

• Long press MODE button to exit, save the current correction modification
